SPECIFICATION :
Frame
Spark 3 Carbon / IMP technology / HMF Mainframe
BB92 / Alloy SL 6011 swingarm
SW dropouts for Boost 148x12mm
TBC Trunnion box construction
Fork
FOX 34 Float Performance Elite Air
FIT4 3-Modes with low speed adj. / 15x110mm QR axle
Tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Shock
FOX NUDE Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / EVOL / Reb. Adj.
Travel 120 - 85 - Lockout / 165X45mm
Remote System
SCOTT TwinLoc TSP Technology
Suspension - Seatpost Remote
Below Bar / 3 modes / integ. Grip clamp
Headset
Syncros FL2.0 Drop in / Tapered 1.5" - 1 1/8"
Bearing diameter size 42mm and 52mm
Rear Derailleur
Sram X01 / Eagle 12 Speed
Front Derailleur
SCOTT Chainguide
Shifters
Sram X01 Trigger
Brakes
Shimano XT M8000 Disc
180mm F & R / SM-RT64 CL Rotor
Crankset
Sram X1 1400 Eagle GXP Boost PF
700 Series: 34T / 900 Series: 32T
BB-SET
Sram GXP PF integrated / shell 41x92mm
Handlebar
Syncros FL1.5 T-Bar / Alloy 7050 D.B.
T shape Flat / 9° / 740mm
Syncros Pro lock-on grips
Handlebar Stem
Syncros FL1.5 / Alloy 2014
Integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Seatpost
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M, L & XL 125mm
Seat
Syncros XR1.5 / Titanium rails
Hub (Front)
Syncros XR2.0 CL / 15x110mm
Made by DT Swiss
Hub (Rear)
Syncros XR2.0 CL / Boost 148x12mm
RWS axle / Made by DT Swiss
Chain
Sram PCX01 Eagle
Cassette
Sram X01 / XG1295 / 10-50 T
Spokes
DT Swiss Competition 2.0-1.8-2.0 Black
Rims
Syncros XR2.0 / 28H / Tubeless ready
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx speed
